Name: PIX4D viDoc RTK scanner
SKU: vidoc-rover
Price: 5940.00 USD
Availability: InStock

In Stock

PIX4D viDoc RTK scanner

Prices Starting at: $5,940.00

viDoc RTK scanner. Easy digitalization with Pix4D software that can measure single points or create line work from data capture. Easy for anyone to collect points or complete an accurate 3D scan. The handheld scanner combines with mobile software to create digital twins as fast as possible.

Part Number

Vidoc RTK Scanner

Clear

SKU: vidoc-rover Categories: Pix4D, GNSS / GPS Tags: rtk, vidoc, pointcloud, catch, pix4d, mapper, photogrammetry, mapping, software, microdrones Brand: Pix4D

Description

PIX4D viDoc® RTK scanner for selected iPhone and Android devices

*Pix4DCatch can be used on Android and iPhones. viDoc only works on iPhone Pro Series with built it LiDAR feature.

Use a handheld RTK scanner to elevate single point measurement with 3D scans

IMA_vidoc_RD_2022_laser_5

IMA_vidoc_RD_2022_obstructed_points_6

IMA_vidoc_RD_2022_multiple_options_4

Multiple options for accurate point measurement

Measure with the laser, photogrammetry, or attach it to a surveying rod.

Measure obstructed points

Complete data collection without missing anything that may be obstructed by objects like trees or overhangs.

Accurate and safe measurement methods

Get your measurements and reduce risks – cut unnecessary trench visits, etc. Make data collection safer.

Vidoc-7

Vidoc-8

Vidoc-9

The viDoc RTK scanner with PIX4Dcatch:

Accurate surveying with a mobile device

Easy field-to-finish workflows

Easy digitalization with Pix4D software that can measure single points or create line work from data capture.

RTK positioning scanner for 3D scanning

viDoc RTK scanner pairs with the PIX4Dcatch to geotag images of the 3D scan in real-time using NTRIP services

Enhanced mobile data collection

viDoc connects to over 600 channels (including all major constellations such as GPS, GLONASS, Galileo, etc.) which results in convergence in under 5 seconds.

Replacing complex workflows

Ground surveying equipment like laser scanners can be expensive, bulky, and highly technical. Drones can be restricted by regulations. Overcome the obstacles with a handheld scanner.

A complete, accurate workflow in your hands

The viDoc, the smartphone, PIX4Dcatch, and PIX4Dcloud. An end-to-end solution that gets measurements at centimeter level absolute accuracy.

Intuitive feel and structure

Easy for anyone to collect points or complete an accurate 3D scan. The handheld scanner combines with mobile software to create digital twins as fast as possible.

*viDoc® Yearly license. Save up to 64% on the AEC Software Bundle when purchased with the viDoc.

Annual license for the ultimate AEC hardware software bundle.

Get centimeter accurate terrestrial scans with the viDoc, and process results with PIX4Dmatic. Seamless integration between desktop and cloud 2D and 3D processing for advanced project analysis. Leverage the power of both photogrammetry and terrestrial LiDAR for fast terrestrial, corridor, and large scale mapping with PIX4Dmatic. Apply advanced automation to extract the data you need from point clouds and create CAD-ready deliverables with PIX4Dsurvey. PIX4Dmatic and PIX4Dsurvey combined with our online platform for terrestrial and drone mapping allow streamline progress monitoring, site documentation, and collaboration.

Quick Specifications

8 hours of battery operation
RTK function enables high precision in the measurement up to 1cm+1ppm

Documents:

In the box:

1x viDoc for Smartphone
1x USB charging cable
1x heavy duty carrying box
1x Pix4DCatch
1x Pix4DMatic (Hardware bundle only)
1x Pix4DSurvey (Hardware bundle only)
1x Pix4DCloud / Advanced – OneYear (Hardware bundle only)

Additional information

Weight	5 lbs
Part Number	Vidoc RTK Scanner

Specifications

Vidoc

ViDoc	Smartphone	Tablet
Measurement	153x72x19mm
Weight	242g
Temp Range	–5 up to +35 °C	–5 up to +35 °C
Humidity	5–95 % (not condensing)	5–95 % (not condensing)

GNSS antenna	Smartphone
Measurement	55,6 mm x 27,5 mm
Weight	< 19 g
Temp Range	–40 up to + 80 °C
Humidity	Up to 95 %
Polarizatin	RHCP
Satellite Signals	GPS: L1/L2 GLONASS:G1/G2 Beidou: B1/B2/B3 Galileo: El/E5b
Coverage	360°
Supply Voltage	3 – 16 VDC
Power Consumption	< 35 mA
Gain	36 ± 2 dB
Noise Figure	< 1,5 dB
V.S.W.R	< 2,0

Laser	Smartphone
Measurement accuracy	± 2 mm
Measuring range	Ground laser: 0,5 – 40 m Front laser: 0,5 – 20m
Laser class	2
Laser type	635 nm, < 1 mW
Measurement times	0,1 up to 4 sec.
Supply Voltage	2,5 – 3,3 V
Operatin temperature	0 up to 40 °C
