Description

Tri-Max Wood Dual Clamp Instrument Tripod

In side-by-side tests with leading competitors, the Tri-Max Wood shows decreased drift over time, increased stability, and increased vibration isolation.

The Tri-Max®, designed and manufactured by SECO, is the only surveying grade tripod with certified accuracy – highly recommended for all servo driven and robotic total stations, 3-D laser scanners or construction lasers

• The revolutionary design of this tripod series means this tripod will meet ISO standard (12858-2-H) right out of the box, and after years of field use
• Features a 6.5-inch Flat head with large center hole (2-5/8 inch) to facilitate an easy set-up over a point
• Solid one piece 5/8-11 instrument fastener with solid, one-piece 303 Stainless Steel instrument fastener bridge
• The large foot is designed specifically for surveyors who have asked for wide, angled tabs to allow even muddy boots to have a secure grip when setting up
• Tested to ASTM G154 weather standard for long life in harsh conditions
• Brass bushings ensure stability and long life
• Individual SN for ID and inventory control
• The Tri-Max can handle equipment up to 65 lb (30 kg)
• Dual Clamp Lock type
• Black Hardware, Sealed Hardwood Legs
• Length Extended: 71 inches (183 cm)
• Length Collapsed: 45 inches (114 cm)
• Weight: 19.65 lb (8.9 kg)
