In Stock

Emlid Reach RCH205 RS3 RTK GNSS receiver with tilt compensation

$2,799.00

Reach RS3 gets a centimeter-accurate solution in about 5 seconds. It maintains robust performance even when the sky view is partially obstructed, or the receiver itself is tilted.

SKU: RCH205 Categories: , , , , , , , Tags: , , , , , , , , , , , Brand:

Description

Emlid Reach RCH205 RS3 RTK GNSS receiver with tilt compensation

Multi-band base and rover  |  IMU tilt compensation  |  LTE modem  Built-in radio

Accurate results even with large tilt angles

The IMU-based tilt compensation in Reach RS3 enables you to make measurements with up to 60 degrees of tilt while still staying within 20 mm of accuracy.
Reach RS3 continuously measures and corrects tilt in real-time to keep you on target.

Survey and stakeout faster
No need to check the bubble

Effortless and robust
IMU tilt compensation

Calibration-free

We calibrate the inertial measurement unit in each device individually at the factory, so you can get your Reach RS3 up and running right out of the box.

Immune to magnetic disturbances

Unaffected by magnetic fields, RS3’s IMU sensors provide robust tilt compensation even when working close to metal structures.

Quick initialization

Tilt initialization takes about 20 meters of walking or 10-20 seconds of tilting. Usually ready on the way from the car.

Rapid and Reliable GNSS receiver

Gets a fix in 5 seconds
Reach RS3 gets a centimeter-accurate solution in about 5 seconds. It maintains robust performance even when the sky view is partially obstructed, or the receiver itself is tilted.

GPS/QZSS, GLONASS, BeiDou, and Galileo

L1C/A, L2C, L1OF, L2OF,B1I, B2I, E1B/C, E5b

RINEX logging and PPP support
Up to 22 hours on 1 charge
Built-in LTE modem

Get corrections from CORS, Reach, or 3rd-party base

NTRIP
Base and Rover
Work in RTK with VRS or a single baseline CORS network. You
can also connect another GNSS receiver as an NTRIP base using Emlid NTRIP Caster.

Compatibility
Any receiver with RTCM3 support

Quick Specifications:

  • Corrections:  NTRIP, RTCM3
  • Data Logging:  RINEX, NMEA, LLH/XYZ, UBX
  • Internal Storage:  16GB
  • IP67 RS3 is waterproof up to a one meter depth.  Silicone plugs completely seal and protect all connectors from water and dust.
  • -20 to +65 ºС  Extensively tested the Reach RS3 in conditions that simulate the coldest winters and hottest summers.
  • Weight:  950 grams
  • Dimensions:  126 x 126 x 142 mm

What’s in the box:

  • 1x Emlid REACH RS3 GNSS Receiver
  • 1x LoRa Antenna
  • 1x USB cable
  • 1x Carrying case with a strap
