Nedo Industrial Line Elevating Tripod
Most elevating tripods are designed for the use of rotating lasers. However, laser scanners place different demands on an elevating tripod. Laser scanners are usually heavier than rotating lasers. In addition, the use of laser scanners requires more frequent height adjustment of the tripod. To meet these special requirements, Nedo has developed the Industrial Line tripod range. Perfectly matched to the use of laser scanners.
Features:
- Indirect crank drive for easy height adjustment
- Reinforced gear unit that works almost wear-free even in continuous operation
- Twist-proof crank column with centric clamping
- Tripod legs made of reinforced aluminum profiles and leg braces for additional stability
- Combination tripod shoes for an optimal stand on different floors
Technical specifications:
- Min. usable height approx. 1.13 m
- Max. usable height approx. 2.76 m
- Transport length approx. 1.28 m
- Weight approx. 9.3 kg
- Retaining screw: 5/8” thread
- Support plate flat, Ø 110 mm
- Crank stroke 910 mm
- Aluminum tripod plate and joints
- mm scale on telescopic tube
In the box
- 1x Shaft tripod including base tooth column
- 4x extensions, each 1 m in a bag
- 1x SW5 Allen screwdriver
- 1x magnetic bit holder for a cordless screwdriver
- 1x hand crank with magnetic bit holder
- 1x set of combination tripod shoes
- 1x 3/8″ tripod adapter
